Technical Specifications
Peel 3 is an easy and intuitive technology that will bring portability, versatility, and ease of use to your educational 3D scanning projects.
Software
Peel.EDU: VXelements, VXmodel & VXinspect|Elite
Part size range (recommended)
0.1 - 3.0 m
Accuracy(1)
0.250 mm/m, up to 0.1 mm
Measurement capabilities (at a working distance of 0.5 m (1.65 ft))
pin 1.5 mm
hole 3.0 mm
step 0.1 mm
wall 1.0 mm
Mesh resolution
0.250 mm
80 sec/m2
Working Distance
250 to 550 mm
Light source
IR VCSEL
Touchscreen
50 - 200 DPI
Dimensions
(LxWxH)
(LxWxH)
304 x 150 x 79 mm
Weight
950 g
Connection standard
USB 3.0
